In this article I’m going to be taking a quick look at the Samebike MY-SM26 electric bike. This budget e-bike is currently available for under €800, and unlike most of its rivals uses a 48v battery. As soon as I can get hold of one, I’ll post a full review here.
Summary
Contents
Samebike are a Chinese e-bike manufacturer who sell affordable electric bikes specifically to the European market. Their range of bikes are currently available for shipping within the EU from geekbuying.com.
Electric components
The Samebike MY-SM26 uses a 350w brushless, geared rear hub motor in conjunction with a 48v 8Ah battery (384Wh). The main benefit of a 48v battery over a 36v, is the motor will draw less current to achieve the same power (as a 36v), meaning it will run slightly cooler and be more efficient.
The e-assist system is controlled by by a keypad located near the left-hand gear shifter and a centrally-mounted LCD display. All the usual functionality is available including speed, assist level indicator, trip computer and battery range indicator.
This e-bike can be used as a regular bike, in pedal assist mode and also throttle mode. ⚠ It should be noted that the rated power output of 350w exceeds the 250w allowed by EU e-bike laws.
Check out the best electric mountain bikes for under £1000 / €1000
Bike components
All of the components used on the MY-SM26 are basic, but functional. There’s a triple front chainset with 6-speed rear freewheeel giving a total of 18 gears. The rear derailleur and shifters are Shimano, so will be of good quality.
Front suspension forks will help soak up potholes and poor road surfaces and also enable the rider to take on some mild to moderate off-road trails. The fork is a basic coil-sprung design and has a lock-out feature for riding on the road.
Braking is provided by front and rear mechanical disc brakes which should provide adequate stopping power for day to day use.
The 26″ tyres have some puncture protection and the tread will be ideal for a mixture of road riding and gravel tracks / forest trails.
Buy from geekbuying and 👉(use discount code NNNINFLUENCER500)
Specification
| General | Brand: Samebike Type: Electric Bike Model: MY-SM26 Colour: Black / White |
| Specification | Material: 6061 aluminium Wheel Size: 26×1.95 inch Max Load: 150kg Max Speed: 30km/h Max Uphill: 25° Temperature: -10-40°C Battery Cells: Lithium 18650 Battery: 48v 8 AH Battery Total Energy Capacity: 384WH Electrical Start-up Mode: Pedal/throttle/pure electric mode Pure Electric Mode: 35-40km Pedal assist mode: 70-80km Motor Rated Power: 350W Rated Voltage: 48V Charger Input Voltage: 110~240V Charging Time: 4-6 hours Front Light: Yes Display: LCD Brakes: Front/rear mechanical disk brake |
| Weight & Dimensions | Net weight: 21kg Gross weight: 25kg Bike size (assembled): 170 x 102 x 102 cm Package size: 136 x 24 x 73 cm |
| Package Contents | 1 x Electric Bike 1 x Charger 1 x Vehicle Tools 1 x User Manual |
Conclusion
At its current price of under €800, the Samebike MY-SM26 certainly looks like good value for money. It’s one of the very few electric bikes in this price range that uses a 48v battery.
Apart from the 48v battery, everything else is what you would expect to see on a budget e-bike. The mag wheels will be tough and long-lasting (no more broken spokes) and the battery should give a realistic range of 40-50km. If you’re after a cheap electric bike for commuting or a general runabout, then the Samebike MY-SM26 is a good alternative to the likes of the Ancheer Pro.
Buy from geekbuying and 👉(use discount code NNNINFLUENCER500)
Thanks for reading, if you own an Samebike MY-SM26, please feel free to leave a review in the comments section below.
I own a Samebike my-sm26 for about a year now. First half a year i drove 30km’s a day. With no cleaning (at all) and completely ignore the whole thing after 1200km’s the following service parts needed replacement:
Chain, derailleur sprockets and the rear tire where worn and replaced.
In addition i used the bike for jumping over speedbumps on the road while maintaining hand throttle. The shop advised me to not do that to often due to a loose bearing inside the steering pin. They torqued it and they put heat shrinks on all of the connectors as a pre caution.
After about a total of roughly 1350km the bike shut down during driving. Since the last service i have not jumped at all with the bike. But when taking a hard corner all power was lost and the bike will not turn on again.
I am currently looking for the issue myself. Mind you, i ramped up the speed of the bike to about 35km/h within 2 weeks after purchase. This is really a decent bike for the money. I bought it of Ali-express for 750 euro
Je viens de recevoir mon VTT électrique Samebike aujourd’hui mais j’avais pas le manuel de montage mais j’ai réussi à le monté sauf l’écran led au guidon comment brancher et l’allumer j’ai rechargé la batterie je fais comment maintenant svp merci pour une réponse le plus vite possible
Vous devrez vérifier le connecteur circulaire qui relie l’écran au faisceau de câblage principal. De plus, il y a un interrupteur marche/arrêt sur le côté de la batterie (bouton rouge) qui doit être allumé avant de pouvoir démarrer le vélo. > Voici un lien vers le site Samebike avec des instructions vidéo.
Je viens d’acheter ce vélo dans les montées raides je ne peux pas dépasser la puissance 5 alors que normalement je devrais aller jusqu’à 8. Comment faire
Io non riesco ad accenderla…? aiutatemi!!!GRAZIE
